Wire-Wrap Banana Jacks – Model 4022-0, Dual-Terminal Design

Description

• Jack: Nickel Plated Brass
• Terminal: Gold Plated Phosphor Bronze
• Insulation: Polycarbonate molded to Banana Jack body
• Panel Insulator: Polycarbonate. Color matches color of Banana Jack insulation.
• Lockwasher #8 Internal Tooth: Steel. Nickel plated per QQ-N-290 Class 2, 200/300 microinches.
• Wrapped Wire Terminal: Beryllium Copper. Gold plated per MIL-G-45204, Type II Class 00 over electroless nickel per MIL-C-26074, Class 1, 200/300 microinches.
• Operating Temperature: +115°C (+239°F) Max.
• Operating Voltage: 1500 VDC
• Current: 3 Amperes
