TL071 Low-Noise JFET Single Operational Amplifier IC – Linear Precision Circuit

Description

The TL071 is a high-speed JFET input single operational amplifier. This JFET input operational amplifier incorporates well matched, high-voltage JFET and bipolar transistors in a monolithic integrated circuit. The device features high slew rates, low input bias and offset currents, and low offset voltage temperature coefficient. Wide common-mode (up to VCC+) and differential voltage range.

• Low Noise JFET Single Operational Amplifier
• Low input bias and offset current
• Low noise en = 15 nV/ √Hz (typ)
• Output short-circuit protection
• High input impedance JFET input stage
• Low harmonic distortion: 0.01 % (typ)
• Internal frequency compensation
• Latch-up free operation
• High slew rate: 16 V /µs (typ)
