IBM-Compatible AT-Bus Prototyping Board: Full-Length (13.125″ × 4.4375″)

Description

4.25″ x 13.13″. Double sided pads with plated through holes. I/O area for D-sub 9 to 25 pin connector. Separate busses for power and ground. 16 bit 49/98 contacts on 0.1 center. .042″ diameter holes on 0.1″ grid.

• 13 1/8″ x 4 7/16 AT-Bus Prototyping Board
• Board Length: 13-1/8” (333mm)
• Board Width: 4-5/16” (110mm)
• Double Sided, Pad-Per-Hole and Power Buses
• Space Reserved for: 1 D-Type Connector, 25-Pin
