100 mH Encapsulated RF Choke — 30 mA, 150 Ω DC Resistance

Description

• Type: Radio Frequency Choke
• Inductance: 100 mH
• Maximum DC Current: 30 mA
• Maximum DC Resistance: 150 Ohms
• Termination: Through Hole
• Electrical Specifications:
• Inductance L: 100mH (±10%)
• Test Frequency: 25.2 KHz
• Q Min: 30
• DCR Max: 150Ω
• Wire Diameter: 0.08
• Turns REF: 1590 TS

General Specifications:

• Resistance to solder heat: 260°C 10 Sec.
• Hand Soldering Temperature: 350°C ~ 400°C 3~5 Sec.

Size:

• Diameter: 10.7mm
• Height: 14.4mm (not including leads)
• Lead length: 10mm
• Distance between leads: 4.5mm
